Sheet laser cutting
HF-3015G Series High Speed Fiber Laser Cutting Machine
A fully enclosed, dual-platform fiber laser cutting system for high-speed, high-precision sheet metal production. The HF-3015G is configured for carbon steel, stainless steel, aluminium, brass and other thin-to-medium plates, with a shuttle-table workflow that keeps loading, unloading and cutting moving efficiently.
Fully enclosed
Exchange platform
FSCUT control
HF3216G-9X machine introduction video
Product overview animation
A quick visual walk-through of the HF-3015G system.
This overview animation helps buyers understand the enclosed body, exchange-platform workflow, cutting area and machine layout before comparing laser power, automation and local service options.
Product description
Production-ready cutting for everyday sheet metal work.
The HF-3015G is designed as a professional dual-platform sheet laser for workshops that need stable output, clean enclosure, fast exchange-table handling and a familiar operating environment. It brings the machine body, drive system, optical path, pneumatic system, dust extraction and laser cutting software into a matched production package.
Fully enclosed shuttle-table production
The enclosed body and exchange platform help separate the cutting area from the loading area, supporting safer operation and less idle time between sheets.
Heavy-duty machine lathe
The honeycomb heavy-duty lathe and high-strength welded structure are built for long-term rigidity, precision and repeatable cutting performance.
Auto-focus laser cutting head
Auto focus, closed optical path protection, lens monitoring and pressure sensing help keep the cutting process stable across different materials and thicknesses.
Zoned ventilation system
Follow-up segmental ventilation opens the active suction zone only, concentrating airflow where the machine is cutting to improve dust extraction efficiency.
Machine structure
Matched mechanical, optical and control systems.
The HF-3015G combines a high-strength cross beam, precision rack drive, servo drive system, HYMSON auto-zoom cutting head, intelligent pneumatic system and FSCUT control platform. The result is a practical production machine for Australian sheet metal fabricators who need speed, accuracy and serviceable daily operation.
Fiber laser generator
High electro-optical conversion efficiency, compact system integration and stable beam delivery.
Precision gear drive
Ground pinions, racks and gantry drive architecture support fast movement with reduced vibration.
CNC control system
FSCUT supports cutting process control, nesting workflow, diagnostics and production assistance.
Performance indexes
HF-3015G technical highlights.
Core data for quick comparison before preparing a formal quotation and site layout.
Equipment modelHF-3015G
Laser power6000W-12000W
Effective cutting range3100mm x 1550mm
X/Y-axis positioning accuracy±0.03mm/m
X/Y-axis positioning speed140m/min
Maximum X/Y acceleration1.5g
Maximum Z-axis speed40m/min
Control systemFSCUT
Floor space8700mm x 2800mm
Function videos
Show the intelligent cutting functions in action.
Machine video
See the HF-3015G machine in motion.
Use the supplied machine video to show real equipment scale, enclosure design and production presence before the buyer requests a quotation.
Project enquiry
Tell us what you cut. We will help narrow the machine options.
Share the product you are considering, your material mix, thickness range, part size, production volume and timeline. RoboLaser can then recommend a practical configuration.
